QMRITools`
QMRITools`

AnnalyzeTagging

AnnalyzeTagging[gridC]

tracks the motion in tagged cine data gridC, which is {slices, frames, y, x}. The wave vectors of the tag grid are estimated from the power spectrum of the first frames. Per slice the displacement between consecutive frames is estimated from the phase of the band pass filtered tag images for each tag direction and accumulated over the frames. Output is {{ux, uy}, {im0, im, w0, w}}, all {slices, frames, y, x}, where ux and uy are the accumulated displacements in pixels along the first and second image dimension, im0 are the reference images, im the motion corrected frames and w0 and w the corresponding tag grid weighting maps.

Details and Options

  • The following options can be given:
  • HistoryWeighting0.7HistoryWeighting is an options for AnnalyzeTagging. It is the weight of the new frame when updating the reference image, reference = (1 - w) reference + w frame.
    MonitorTaggingTrueMonitorTagging is an options for AnnalyzeTagging. If True the intermediate images and displacements are shown during the calculation.

Related Guides

    ▪
  • TaggingTools
